Introducing the DSRHD10-13 Rectifier from Diodes Incorporated

The DSRHD10-13 from Diodes Incorporated is a high-performance surface-mount Schottky Barrier Rectifier designed to meet the demanding needs of modern electronic applications. This component is an ideal choice for engineers looking for a rectifier that provides low forward voltage drop, high current capability, and superior thermal performance.

Key Features

• Low Forward Voltage Drop: The DSRHD10-13 offers a low forward voltage drop, which enhances power efficiency and reduces thermal issues, making it suitable for high-efficiency power supplies and energy-sensitive applications.
• High Current Capability: With its robust design, this rectifier can handle a high forward surge current, ensuring reliable performance even under stressful conditions.
• Surface-Mount Package: The device comes in a compact, surface-mount DO-214AB (SMC) package, which saves valuable board space and is suitable for automated assembly processes.
• High-Temperature Operation: Capable of operating at high temperatures, the DSRHD10-13 is designed to maintain stability and performance even in environments with elevated temperatures.
• Lead-Free and RoHS Compliant: This product complies with environmental regulations, including RoHS, making it a responsible choice for environmentally conscious manufacturers.

Applications

The DSRHD10-13 is versatile and can be used in a variety of applications, such as:

• Power supply units (PSUs)
• DC-DC converters
• Freewheeling diodes in converters and motor control circuits
• Reverse battery protection
• Automotive applications that require high reliability

Technical Specifications

The DSRHD10-13 boasts impressive technical specifications, including a maximum repetitive peak reverse voltage of 100V, a maximum average forward rectified current of 1.0A, and a peak forward surge current of 40A. Its low forward voltage drop and fast switching capability make it an efficient choice for high-frequency applications.

Diodes Incorporated is renowned for its commitment to quality and reliability, and the DSRHD10-13 is no exception. It's a testament to their commitment to providing components that enhance the performance and efficiency of electronic systems worldwide.
