Product Overview: Texas Instruments LM13700M Dual Operational Transconductance Amplifiers

The LM13700M by Texas Instruments is a versatile dual operational transconductance amplifier (OTA) that provides a perfect blend of performance and flexibility for a wide array of analog applications. This integrated circuit is designed to offer excellent operational characteristics, making it an ideal choice for designers who require a reliable component for signal processing tasks.

Key Features:

• Transconductance Amplifiers: The device includes two independent OTAs, each with a differential input and a push-pull output.
• Linearizing Diodes and Buffers: Built-in linearizing diodes and buffers on the chip enhance performance and reduce external component count.
• Wide Dynamic Range: The LM13700M is capable of providing a wide dynamic range, which is essential for audio applications and various modulation tasks.
• Adjustable Biasing: Users can adjust the amplifier bias current, enabling the control of the amplifier's transconductance.

Applications:

The LM13700M is adept at handling various applications, including but not limited to:

• Audio signal processing
• Voltage-controlled filters
• Voltage-controlled oscillators (VCOs)
• Modulators and demodulators
• Analog computing functions

Technical Specifications:

The LM13700M operates over a supply voltage range of +/-4V to +/-18V, making it suitable for many different power environments. It comes in a 16-pin SOIC package, ensuring compatibility with standard surface-mount technology (SMT) processes. The device also features a low total harmonic distortion (THD), which is pivotal for high-fidelity audio applications.

Quality and Reliability:

Texas Instruments is known for its commitment to quality, and the LM13700M is no exception. It is designed to meet the rigorous standards of the industry, ensuring a reliable performance in the most demanding environments. Whether you're designing a professional audio mixer or an intricate analog synthesizer, the LM13700M offers the precision and durability needed for your project.
