Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Linear Technology
Packaging Tube
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Full
Receiver Hysteresis 25mV
Data Rate 20Mbps
Operating Supply Voltage 3 V ~ 3.6 V
Operating Temperature Range -40°C ~ 85°C
Mounting SMD
Package 16-SSOP (0.154", 3.90mm Width)
Manufacturer Package 16-SSOP
Win Source Part Number 782996-LTC2855IGN#PBF
Popularity Medium
Supply and Demand Status Limited
Family Name LTC2855
Introduction Date January 16, 2007
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LTC2855IGN#PBF CAD Model

Description

Product Overview: LTC2855IGN#PBF

The LTC2855IGN#PBF is a robust transceiver component from Linear Technology, designed to provide reliable communication in industrial and networking applications. This product is part of the LTC2855 series, which is known for its high performance and resilience in challenging environments.

Key Features

  • Interface: The LTC2855IGN#PBF is equipped with an RS485/RS422 interface, ensuring compatibility with a wide range of communication standards. This makes it suitable for serial data transmission over long distances and in electrically noisy environments.
  • Integrated Protection: The device features built-in protection against overvoltage conditions, which can occur in industrial settings. It can withstand voltage faults up to ±60V on the transceiver interface pins, safeguarding the device from electrical damage.
  • High-Speed Operation: It supports data rates up to 20Mbps, allowing for fast and efficient data transfer, which is essential for modern industrial applications that require quick response times and high throughput.
  • Low Power Shutdown: The LTC2855IGN#PBF includes a low power shutdown mode that reduces power consumption when the transceiver is not in use, contributing to energy savings and extended system battery life.
  • Extended Temperature Range: This product is designed to operate reliably over a wide temperature range from -40°C to 85°C, making it suitable for outdoor applications and other environments with temperature extremes.
  • Duplex Configuration: It supports both half-duplex and full-duplex configurations, providing flexibility in communication protocol design and allowing for bidirectional communication.

Applications

The LTC2855IGN#PBF is ideal for a variety of applications, including:

  • Industrial Control Systems
  • Networked Devices in Harsh Environments
  • Automated Factory Equipment
  • Building Management Systems
  • Remote Sensors and Actuators

Package and Quality

The LTC2855IGN#PBF comes in a 16-lead SSOP package, providing a compact footprint for space-constrained applications. Linear Technology ensures high-quality standards, and this product is RoHS compliant, meeting the environmental and safety regulations for electronic components.

In summary, the LTC2855IGN#PBF is a versatile and robust transceiver that offers high-speed communication, advanced protection features, and reliable performance in extreme conditions, making it a top choice for engineers and designers in the industrial and networking sectors.
