MIC29372WU

Part No MIC29372WU
Manufacturer Microchip Technology
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO ADJ 0.75A TO263-5
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 26V
Nominal Output Voltage (Min/Fixed) 1.24V
Maximum Output Voltage 26V
Dropout Voltage-Max 0.75V @ 750mA
Output Current 750mA
Operating Supply Current 300μA to 16mA
Control Features Enable
Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Adjustable
Output Voltage 1.24 V to 26 V
Voltage - Dropout (Typical) 0.37V @ 750mA
Mounting SMD (SMT)
Case / Package TO-263-5
Win Source Part Number 083585-MIC29372WU
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MIC29372WU CAD Model

Description

Product Overview: MIC29372WU from Microchip Technology

The MIC29372WU is a robust, high-current, low-dropout voltage regulator designed by Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions. This regulator is well-suited for a variety of applications, ranging from automotive to industrial and consumer electronics, where a stable and reliable power supply is crucial for optimal performance.

Key Features:

  • High Current Output: The MIC29372WU is capable of delivering up to 3.0A of continuous output current, which makes it ideal for powering heavy load circuits.
  • Low Dropout Voltage: With a low dropout voltage, this regulator maintains regulation with minimal difference between the input and output voltage, enhancing efficiency and conserving energy in power-sensitive designs.
  • Adjustable Output: The output voltage can be adjusted from 1.24V to 26V, providing a versatile solution for a wide range of operating conditions and custom voltage requirements.
  • Thermal Overload Protection: The built-in thermal overload protection safeguards the device against excessive temperature rise, ensuring reliable operation and longevity.
  • Short Circuit Protection: The MIC29372WU also features short circuit protection, which helps to prevent damage to the regulator and the connected load in the event of a fault.

Applications:

The versatility of the MIC29372WU makes it suitable for a broad array of applications, including but not limited to:

  • Automotive electronics
  • Industrial control systems
  • Telecommunication equipment
  • Computer and computer peripherals
  • Battery-powered devices

The MIC29372WU is presented in a TO-263 (D2PAK) package, which is designed for surface mount technology and is known for its ability to handle high power levels and its ease of installation. With Microchip Technology's reputation for quality and reliability, the MIC29372WU is a solid choice for designers seeking a high-performance voltage regulator for their power management needs.
