FT230XS-R

Part No FT230XS-R
Manufacturer FTDI, Future Technology Devices International Ltd
Catalog Interface - Controllers
Description IC USB SERIAL BASIC UART 16SSOP
Datasheet
Sample
Rohs State Need to verify
ECAD Module ECAD

Shipping Information

Shipped from HK warehouse
Expected Shipping Date
Ship today if order in (HKT)
Supplier Lead-Time Call for availability
Estimate shipping fee
Enter your destination to get a shipping estimate
Estimate Shipping Fee
Pricing & Ordering $1.572 Historical reference price : is the price that a customer announces that it is willing to pay for this component in the previous period, only for reference.
Quantity
Unit Price
Ext. Price
19+
$2.6850
$51.015
46+
$2.2040
$101.384
71+
$2.1350
$151.585
97+
$2.0660
$200.402
126+
$1.9970
$251.622
168+
$1.7900
$300.720
* The above prices does not include taxes and freight rates, which will be calculated on the order pages.
Availability: 179,900 pieces
MOQ: 19 pcs
Order Increment : 1 pcs
*Need More Quantity? *Request a Bulk Quantity Quotation?
Estimate shipping
Enter your destination to get a shipping estimate

*

Products specifications

Categories Integrated Circuits
Manufacturer FTDI, Future Technology Devices International Ltd
Packaging Reel - TR
Status Active
Protocol USB
Purpose Bridge, USB to UART
Standards USB 2.0
Supply Voltage - Operating 3.3 V to 5 V
Operating Supply Current 8mA
Temperature Range - Operating -40°C to 85°C
Case / Package 16-SSOP
Win Source Part Number 33780-FT230XS-R
Family Name FT230X
Introduction Date February 08, 2012
ECCN EAR99
Country of Origin Indonesia
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Fake Threat In the Open Market 46 pct.
Supply and Demand Status Balance
Alternative Parts
(Cross-Reference)
FT230XS-U;  FT230XQ-R;  FT231XS-T;

Description

FT230XS-R USB to Serial UART Interface IC

The FT230XS-R from FTDI, Future Technology Devices International Ltd, is a compact, high-performance USB to serial UART interface IC that offers an ideal solution for adding USB connectivity to a wide range of electronic devices. It is part of FTDI's advanced X-Chip series and is designed to facilitate seamless communication between a USB port and serial peripherals.

Key Features

  • USB 2.0 Full Speed Compatible: The device complies with USB 2.0 specifications, ensuring reliable data transfer rates of up to 12 Mbps.
  • Integrated Clock Circuit: The FT230XS-R does not require an external crystal, as it features an integrated clock circuit that simplifies the design and reduces external component count.
  • Integrated 2048-Byte EEPROM: This IC comes with built-in memory for storing device descriptors and CBUS I/O configuration, which can be customized to suit specific application requirements.
  • Low USB Bandwidth Consumption: The device is optimized for low USB bandwidth consumption, making it suitable for multi-port serial applications.
  • UART Interface: It provides a full-duplex UART interface, with configurable data format and transmission speeds, supporting a variety of serial communication protocols.
  • Low Power Consumption: The FT230XS-R is designed for low power operation, with an integrated USB battery charger detection feature, making it ideal for battery-powered applications.
  • Driver Support: FTDI provides extensive driver support for multiple operating systems, ensuring easy integration and compatibility with existing software.

Applications

The FT230XS-R is versatile and can be used in a variety of applications, including but not limited to:

  • USB Serial Adapters
  • Point of Sale (POS) Systems
  • Instrumentation and Measurement Devices
  • Industrial Control Systems
  • Consumer Electronics

With its compact SSOP-16 package, the FT230XS-R is perfect for applications where space is at a premium. Its robust design and advanced features make it a dependable choice for engineers and developers looking to integrate USB to serial capabilities into their products.
