5233 Pomona Electronics
Same model may have multiple batches, images only for reference.

5233

Part No 5233
Manufacturer Keystone Electronics
Catalog Battery Holders, Clips, Contacts
Description BATT CONT SPRING A/AA/CR2 1 CELL
Datasheet
5233 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Battery Products - Battery Holders, Clips, Contacts
Mfr Keystone Electronics
Package Bulk
Product Status Active
Battery Type, Function Cylindrical, Contact (Single)
Style Contact Spring (Leaf)
Battery Cell Size A, AA, CR2
Number of Cells 1
Mounting Type Chassis Mount
Height Above Board 0.520" (13.21mm)
Standard Package 100 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.90.4000
Win Source Part Number 546408-5233
Ultra Librarian 3D Model Ultra Librarian 5233 CAD Model

Description

The 546408-5233 is a battery holder contact spring designed for cylindrical batteries.

  • Height Above Board: 0.520" (13.21mm)
  • Battery Cell Sizes: A, AA, and CR2
  • Contact Spring Style: Secure and reliable connection
  • Mount: Chassis Mount
  • Package: Bulk (100 pieces)
  • Quality: High-quality and durable
  • Ideal for: Various battery-powered devices and applications
