LD7820GL Leadtrend
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Manufacturer Leadtrend
Win Source Part Number 77792-LD7820GL
Popularity Low
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LD7820GL CAD Model

Description

The LD7820GL is a low dropout voltage regulator designed for various applications such as notebook, LCD monitor, and set-top box. It features a low dropout voltage of 0.2V @ 1A output current and a maximum input voltage of 18V. With a built-in over-current protection and thermal shutdown, it ensures a safe operation.

  • Dropout Voltage: 0.2V @ 1A output current
  • Maximum Input Voltage: 18V
  • Features: Built-in over-current protection and thermal shutdown
