Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Status Obsolete(EOL)
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 70mV
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating -55°C to 125°C
Win Source Part Number 1063742-LTC485MJ8
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LTC485MJ8 CAD Model

Description

Product Overview: LTC485MJ8 from Linear Technology

The LTC485MJ8 is a low power differential bus transceiver designed by Linear Technology to provide robust data communication on balanced transmission lines. It is a member of Linear Technology's family of interface devices compliant with the RS485 and RS422 standards, ensuring reliable data transmission over long distances and in electrically noisy environments.

Key Features

  • Interface Standards: The LTC485MJ8 is compatible with the RS485 and RS422 communication protocols, making it versatile for a variety of network configurations and applications.
  • Low Power Operation: It operates with a very low supply current, typically 1.5mA, maximizing efficiency and making it ideal for power-sensitive applications.
  • Wide Supply Voltage Range: The device supports a wide supply voltage range from 4.75V to 5.25V, providing flexibility in system design and ensuring stable operation under varying power conditions.
  • High Speed: Capable of transmitting data at speeds up to 2.5Mbps, the LTC485MJ8 is suitable for high-speed data communication requirements.
  • Thermal Shutdown Protection: It includes thermal shutdown protection that disables the driver outputs when the die temperature exceeds a preset limit, preventing damage to the device from overheating.
  • Driver Differential Outputs: The driver differential outputs can handle up to ±60V fault conditions, offering robust performance and resilience to electrical disturbances.
  • Receiver Input Impedance: The receiver has a fail-safe feature that guarantees a known output if the inputs are left open, shorted, or terminated but idle.

Applications

The LTC485MJ8 is suitable for a wide range of applications that require reliable data transmission. It is commonly used in industrial control systems, networked devices in building automation, instrumentation, and any application where multiple nodes communicate over long distances. Its robustness against noise and low power consumption make it an excellent choice for remote sensors and battery-operated devices within industrial networks.

Package and Quality

The LTC485MJ8 is available in an 8-lead SOIC package, providing a compact footprint for space-constrained applications. Linear Technology ensures high-quality and reliability of their products, making the LTC485MJ8 a reliable choice for critical communication systems.

With its combination of speed, low power operation, and compliance with industry standards, the LTC485MJ8 from Linear Technology is a high-performance solution for your data communication needs.
