Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Tube/Rail
Status Active
Protocol RS422, RS485
Number of Drivers/Receivers 4/0
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating 0°C to 70°C
Mounting Through Hole
Case / Package 16-PDIP
Win Source Part Number 072634-LTC487CN#PBF
Ultra Librarian 3D Model Ultra Librarian LTC487CN#PBF CAD Model

Description

Product Overview: LTC487CN#PBF

The LTC487CN#PBF is a robust line driver and receiver pair from Linear Technology, designed to deliver high-performance communication in balanced data transmission systems. This integrated circuit is engineered to provide reliable operation in demanding industrial environments, making it an ideal choice for applications such as network systems, data acquisition, and control systems.

Key Features

  • Interface Type: RS485/RS422
  • Driver Output Voltage: ±5V differential
  • Receiver Input Voltage: ±12V
  • Data Rate: Up to 2.5Mbps
  • Power Supply Voltage: Single 5V
  • Operating Temperature Range: 0°C to 70°C
  • Package: PDIP-14
  • ESD Protection: Enhanced with integrated protection circuitry
  • Low Power Shutdown Mode: Yes, for power-sensitive applications

Product Benefits

The LTC487CN#PBF is designed to simplify the implementation of RS485 and RS422 communication protocols. It supports a wide range of data rates, making it versatile for various communication needs. The integrated ESD protection ensures long-term reliability and robustness, safeguarding the device against electrostatic discharges that are common in industrial settings.

With its single 5V power supply requirement, the LTC487CN#PBF simplifies power management in system design. Its low power shutdown mode further enables energy-efficient operation, which is critical for battery-powered or power-conscious applications. The operating temperature range ensures stable performance across different environments, from room temperature to more extreme conditions.

Applications

The LTC487CN#PBF is suitable for a wide array of applications where reliable data transmission is required. Its high-speed operation and robust design make it an excellent choice for:

  • Industrial control systems
  • Building automation
  • Networked security systems
  • Data acquisition systems
  • Remote sensors
  • Point-of-sale systems

With its PDIP-14 package, the LTC487CN#PBF is also easy to integrate into existing designs, offering a straightforward solution for engineers looking to upgrade or develop new communication interfaces.
