Description

Linear Technology LTC6802IG-2 High Voltage Battery Monitor

The LTC6802IG-2 is a sophisticated high voltage battery monitoring IC designed by Linear Technology, now part of Analog Devices, to address the complex needs of battery management systems, particularly for electric vehicles (EVs), hybrid electric vehicles (HEVs), and large-scale energy storage systems. This integrated circuit is capable of monitoring up to 12 series-connected battery cells for overvoltage, undervoltage, and overtemperature conditions, ensuring safe and efficient operation of the battery pack.

With its high accuracy and robust design, the LTC6802IG-2 is engineered to withstand the harsh environments typically found in automotive and industrial applications. It can measure cell voltages with an accuracy of ±0.25% from -40°C to 85°C, which is crucial for balancing cell states and maximizing battery life and performance.

One of the standout features of the LTC6802IG-2 is its ability to connect in series with multiple ICs to monitor larger strings of batteries without the need for isolating components between ICs. This daisy-chain capability simplifies the design and reduces the overall cost of the battery management system. Additionally, the device includes a precision reference and a high voltage multiplexer, allowing for the direct connection of cell voltages with a common mode voltage up to 1000V.

The LTC6802IG-2 also offers a comprehensive set of diagnostics to ensure reliable operation. It includes open-wire check capabilities to detect any disconnected or damaged wires, ensuring the safety and integrity of the battery monitoring system. Communication with the LTC6802IG-2 is achieved through an isoSPI interface, which provides high-speed, RF-immune communication with the host microcontroller or data acquisition system.

Overall, the LTC6802IG-2 is a high-performance solution for battery monitoring that combines precision, integration, and reliability, making it an ideal choice for advanced battery management systems in demanding applications.
