Products specifications

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Receiver Hysteresis 500mV
Data Rate 120Kbps
Supply Voltage - Operating 5V
Temperature Range - Operating -55°C to 125°C
Mounting Through Hole
Case / Package 16-CDIP
Win Source Part Number 207354-MAX232MJE
Family Name MAX232
Introduction Date April 20, 2000
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Clock & Timing, Automation & Process Control, Sensing & Instrumentation, Test & Measurement
Ultra Librarian 3D Model Ultra Librarian MAX232MJE CAD Model

Description

MAX232MJE RS-232 Interface IC by Maxim Integrated

The MAX232MJE from Maxim Integrated is a powerful RS-232 interface IC designed to provide a reliable communication interface between data terminal equipment (DTE) and data communication equipment (DCE). This chip is specifically engineered to convert TTL or CMOS logic levels to RS-232 levels and vice versa, making it an essential component for serial communication in a wide range of applications.

Constructed with Maxim Integrated's high-quality design and manufacturing standards, the MAX232MJE is capable of withstanding the challenging conditions of industrial environments. It is suitable for use in devices such as modems, printers, and various types of communication equipment where a robust and reliable serial interface is necessary.

Key Features:

  • Dual Driver/Receiver: The MAX232MJE includes two drivers and two receivers, providing the flexibility to support a full duplex serial port or two simplex ports.
  • Wide Supply Voltage Range: It operates with a supply voltage range from 4.5V to 5.5V, making it versatile for use in systems with standard 5V power supplies.
  • On-Chip Capacitors: This device integrates charge pump capacitors on the chip, which reduces external components and simplifies the design process.
  • High Data Rate: The MAX232MJE supports data rates up to 120 kbps, allowing for high-speed data transmission and efficient communication.
  • ESD Protection: It features built-in electrostatic discharge (ESD) protection, ensuring resilience against static electricity and enhancing product longevity.

Applications:

  • Serial data communication
  • RS-232 data interface for peripheral connections
  • Modems and telecommunications
  • Point-of-sale (POS) systems
  • Industrial control and automation

The MAX232MJE's robustness, combined with its ease of integration, makes it an excellent choice for designers and engineers looking to implement or upgrade serial communication capabilities in their projects. With Maxim Integrated's reputation for quality and reliability, the MAX232MJE stands out as a top choice for ensuring stable and efficient RS-232 data exchange.
