SS320C Rugao Dachang Electronics Co., Ltd
Same model may have multiple batches, images only for reference.

SS320C

Part No SS320C
Manufacturer MDD
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 200V 3A
Datasheet
SS320C Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr MDD
Series SMC
Package Tape & Reel
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 200 V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 950 mV @ 3 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 300 µA @ 200 V
Capacitance @ Vr, F 350pF @ 4V, 1MHz
Mounting Type Surface Mount
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 676343-SS320C
Ultra Librarian 3D Model Ultra Librarian SS320C CAD Model

Description

The 676343-SS320C is a Schottky rectifier diode from the SMC series. It has a maximum DC reverse voltage of 200V and an average rectified current of 3A.

  • Maximum DC Reverse Voltage: 200V
  • Average Rectified Current: 3A
  • Forward Voltage Drop @ 3A: 950mV
  • Reverse Leakage Current: 300 µA @ maximum reverse voltage
  • Capacitance @ 4V, 1MHz: 350pF
  • Package: SMC package
  • Manufacturer: MDD
  • Status: active
