Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr Microchip Technology
Package Bulk
Product Status Active
Voltage - Zener (Nom) (Vz) 6.4 V
Tolerance ±5%
Power - Max 500 mW
Impedance (Max) (Zzt) 100 Ohms
Current - Reverse Leakage @ Vr 2 µA @ 3 V
Temperature Range - Operating -65°C ~ 175°C
Mounting Type Through Hole
Package / Case DO-204AH, DO-35, Axial
Supplier Device Package DO-35 (DO-204AH)
Standard Package 1 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0050
Win Source Part Number 539076-1N4574A
Ultra Librarian 3D Model Ultra Librarian 1N4574A CAD Model

Description

The 1N4574A from Microchip Technology is a precision Zener diode that offers a stable zener voltage for voltage regulation and voltage reference purposes. This diode is designed for high-performance applications that require tight voltage regulation and a stable reference voltage over a wide range of operating conditions.

Key Features

  • Zener Voltage: The 1N4574A provides a precise zener voltage, making it an ideal choice for applications that demand a high degree of voltage accuracy.
  • Temperature Stability: With its excellent thermal stability, the diode operates reliably over a broad temperature range, ensuring consistent performance.
  • Low Dynamic Impedance: The dynamic impedance of the diode is low, which contributes to its ability to maintain voltage stability under varying current conditions.
  • High Power Dissipation: This diode is capable of dissipating a significant amount of power, which is beneficial for handling higher current operations.

Applications

The 1N4574A is versatile and can be used in a variety of electronic circuits. Its primary applications include:

  • Voltage regulation for power supplies
  • Reference voltage sources in precision circuits
  • Surge protection in sensitive electronics
  • Waveform shaping and clipping circuits

Specifications

Zener Voltage 6.4V Test Current 5mA Tolerance ±5% Package DO-35 Operating Temperature Range -65°C to +175°C

Quality and Reliability

Microchip Technology is renowned for its commitment to quality and reliability. The 1N4574A zener diode is no exception, meeting stringent standards to ensure it performs to the highest specifications under various conditions.
