Products specifications

Category Discrete Semiconductor Products - Diodes - Rectifiers - Diode Arrays
Mfr Microchip Technology
Package Tube
Product Status Active
Diode Configuration 2 Independent
Technology Standard
Voltage - DC Reverse (Vr) (Max) 300 V
Current - Average Rectified (Io) (per Diode) 30A
Voltage - Forward (Vf) (Max) @ If 1.4 V @ 30 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 25 ns
Current - Reverse Leakage @ Vr 150 µA @ 300 V
Operating Temperature - Junction -55°C ~ 175°C
Mounting Type Chassis Mount
Package / Case SOT-227-4, miniBLOC
Supplier Device Package ISOTOP®
Base Product Number APT2X30
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 564013-APT2X30D30J
Ultra Librarian 3D Model Ultra Librarian APT2X30D30J CAD Model

Description

The APT2X30D30J is a cutting-edge power device from Microchip Technology, designed to deliver efficient and reliable performance for a wide range of applications. This device is a member of the silicon carbide (SiC) power MOSFET family, which is renowned for its high efficiency, faster switching speeds, and improved thermal performance compared to traditional silicon devices.

Key Features

  • Wide Bandgap Technology: Utilizing SiC, the APT2X30D30J offers superior characteristics such as higher breakdown electric field, lower on-resistance, and reduced switching losses.
  • High Voltage Capability: This device is capable of handling high voltages, making it ideal for power supply applications that require a robust voltage tolerance.
  • Low On-Resistance: With its low R<sub>DS(on), the MOSFET ensures minimal power loss during operation, contributing to overall system efficiency.
  • Fast Switching Speed: The fast switching capability of the APT2X30D30J reduces transition losses and allows for high-frequency operation, which is critical for applications like switch-mode power supplies and inverters.
  • High-Temperature Operation: Designed to withstand high operating temperatures, this device maintains performance and reliability even under thermal stress.
  • Enhanced Durability: The rugged construction of the APT2X30D30J ensures a long operational lifespan, even in demanding conditions.

Applications

The versatility of the APT2X30D30J allows it to be used in a variety of applications, including:

  • Power supply units
  • Electric vehicle (EV) chargers
  • Renewable energy inverters
  • Industrial motor drives
  • Power factor correction circuits

Quality and Reliability

Microchip Technology is known for its commitment to quality and reliability, and the APT2X30D30J is no exception. Each device is rigorously tested to ensure it meets the high standards expected by industry professionals. The APT2X30D30J is not only a testament to Microchip's innovative engineering but also to their dedication to providing dependable power solutions.
