Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Switch Type CableCARD Switch
Number of Outputs 3
Output Type N-Channel
Voltage - Load 3.3V, 5V
Current - Output (Max) 150mA
Rds On (Typ) 275 mOhm
Features Load Discharge, Slew Rate Controlled
Fault Protection Current Limiting (Fixed), Over Temperature, UVLO
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 16-QSOP
Win Source Part Number 023248-MIC2569YQS
Ultra Librarian 3D Model Ultra Librarian MIC2569YQS CAD Model

Description

The MIC2569YQS from Microchip Technology is a robust, high-performance integrated circuit designed to provide advanced power management solutions for a wide range of applications. This single-channel power ORing controller chip is engineered to enhance system reliability through seamless power source transitions, making it an ideal choice for redundant power systems, servers, telecom, and datacom equipment.

Key Features

  • Intelligent ORing Control: The MIC2569YQS is equipped with smart ORing control functionality that allows for efficient power sharing and switching between multiple power sources, ensuring uninterrupted operation.
  • Low On-Resistance: This device boasts a low on-resistance (R<sub>ON) FET, which minimizes voltage drop and power loss, enhancing overall system efficiency.
  • Fast Switching Capability: With its fast switching capability, the MIC2569YQS ensures rapid transition between power sources, reducing the risk of system downtime.
  • Wide Operating Voltage Range: The device supports a broad operating voltage range, accommodating various power systems and ensuring compatibility with diverse equipment.
  • Reverse Current Blocking: It includes reverse current blocking to protect against backflow of current, which can be critical for preventing damage to sensitive components.
  • Under-Voltage Lockout (UVLO): The MIC2569YQS features UVLO protection to ensure that the device operates only when the input voltage is within the specified range, safeguarding against undervoltage conditions.

Applications

The MIC2569YQS is versatile and can be implemented in various applications where power redundancy and reliability are paramount. Its suitability for high-availability systems makes it a go-to component for:

  • Redundant Power Supplies
  • Telecommunications Equipment
  • Datacom Infrastructure
  • Industrial Systems
  • Server and Storage Systems

Quality and Reliability

Microchip Technology is known for its commitment to quality and reliability, and the MIC2569YQS is no exception. This product is manufactured to the highest standards, ensuring that it meets the rigorous demands of industrial and commercial applications. For designers and engineers seeking a reliable power ORing solution, the MIC2569YQS offers an exceptional balance of performance, efficiency, and protection.
