EE-SH3 Omron
Same model may have multiple batches, images only for reference.

EE-SH3

Part No EE-SH3
Manufacturer Omron
Catalog Optical Sensors
Description SENSOR OPT SLOT PHOTOTRAN PCB MT
Datasheet
EE-SH3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Optical Sensors - Photointerrupters - Slot Type - Transistor Output
Mfr Omron
Package Bulk
Product Status Obsolete
Sensing Distance 0.134" (3.4mm)
Sensing Method Through-Beam
Output Configuration Phototransistor
Current - DC Forward (If) (Max) 50 mA
Current - Collector (Ic) (Max) 20 mA
Voltage - Collector Emitter Breakdown (Max) 30 V
Response Time 4µs, 4µs
Temperature Range - Operating -25°C ~ 85°C
Mounting Type Through Hole
Package / Case PCB Mount
Type Unamplified
Standard Package 50 pcs
MSL Level Not Applicable
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 588268-EE-SH3
Ultra Librarian 3D Model Ultra Librarian EE-SH3 CAD Model

Description

The EE-SH3 is a slot-type photointerrupter with a transistor output. Omron manufactures it.

  • Sensor Type: Unamplified optical sensor
  • Package: Bulk (50 pieces)
  • Response Time: 4µs
  • Voltage Breakdown: 30V
  • Collector Current Rating: 20mA
  • Forward Current: 50mA
  • Sensing Method: Through-beam
  • Sensing Distance: 0.134 inches (3.4mm)
  • Operating Temperature: -25°C to 85°C
