Products specifications

Manufacturer Rohm Semiconductor
Win Source Part Number 1155907-BU9735K
Manufacturer Homepage www.rohm.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian BU9735K CAD Model

Description

The BU9735K is a PMIC (Power Management Integrated Circuit) specifically designed as a display driver manufactured by Rohm Semiconductor. Its primary function is to manage the power supply and control the operation of displays, such as LCD panels, LED matrices, and other visual output devices. It provides essential functions such as voltage regulation, current control, and timing synchronization, ensuring optimal display performance and efficiency.

Applications

  • Automotive navigation systems: Powers and controls the LCD screens used in car navigation devices.
  • Portable media players: Drives the displays in portable DVD players, tablets, and other media devices.
  • Industrial control panels: Manages the display units used in industrial automation and monitoring systems.
  • Consumer electronics: Integrated into various display-based devices such as digital photo frames and e-readers.
  • Gaming consoles: Controls and manages the display output for handheld gaming devices.

Features

  • Integrated voltage regulators: Provides stable and efficient power supply to the display panel.
  • Adjustable brightness control: Allows for precise adjustment of display brightness to optimize visibility and power consumption.
  • Over-voltage and over-current protection: Protects the display panel and the PMIC from damage due to electrical faults.
  • Short-circuit protection: Prevents damage from short circuits, enhancing the reliability of the system.
  • Compact package: Enables integration into small form-factor devices.

Benefits

  • Optimized display performance: Ensures stable and reliable display operation, resulting in improved image quality and clarity.
  • Reduced power consumption: Minimizes energy usage, extending battery life in portable devices and reducing operating costs.
  • Enhanced system reliability: Protects the display panel and the PMIC from damage, minimizing the risk of system failures.
  • Simplified system design: Reduces the complexity of system design by integrating multiple power management functions into a single chip.
  • Increased design flexibility: Allows for easy integration with a wide range of display panels, providing greater design flexibility.

Additional Details

The BU9735K typically supports various display interfaces, such as RGB, SPI, and I2C. It operates within a specific input voltage range and provides multiple output voltage rails to power different sections of the display panel. The datasheet contains detailed electrical characteristics, timing diagrams, and application notes. The package type and thermal resistance influence its suitability for different applications and operating conditions.
