Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - LED Drivers
Mfr STMicroelectronics
Package Tube
Product Status Discontinued
Type AC DC Offline Switcher
Topology Flyback
Internal Switch(s) Yes
Number of Outputs 1
Voltage - Supply (Min) 11.5V
Voltage - Supply (Max) 23V
Frequency 166kHz
Dimming PWM
Temperature Range - Operating -40°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154", 3.90mm Width)
Supplier Device Package 16-SO
Base Product Number HVLED815
Standard Package 50 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 599925-HVLED815PF
Ultra Librarian 3D Model Ultra Librarian HVLED815PF CAD Model

Description

Overview of HVLED815PF - High-Efficiency LED Driver

The HVLED815PF from STMicroelectronics is an advanced LED driver designed to deliver high efficiency and reliability for lighting solutions. This innovative component is a member of ST's LED driver family that integrates a high-voltage MOSFET capable of handling up to 800V, making it suitable for a wide range of LED lighting applications, including indoor and outdoor environments.

Key Features

  • High-Voltage Capability: The integrated 800V avalanche-rugged MOSFET allows the HVLED815PF to easily manage large voltage swings, ensuring robust performance in fluctuating electrical environments.
  • Energy Efficiency: With a quasi-resonant zero-voltage switching (QR-ZVS) topology, the device maximizes efficiency by minimizing switching losses, making it an eco-friendly choice for energy-conscious applications.
  • Flexibility: The HVLED815PF supports both isolated and non-isolated configurations, providing versatility for designers to implement in various lighting schemes.
  • Advanced Protection Features: The device includes several protection mechanisms such as overcurrent, overvoltage, and thermal shutdown, which contribute to the safety and longevity of the lighting systems.
  • Dimming Capability: It offers analog and digital dimming control, enabling precise brightness management to create the desired ambiance or meet energy-saving requirements.

Applications

The HVLED815PF is a perfect choice for a range of LED lighting applications, including but not limited to:

  • LED Bulbs and Tubes
  • Street Lighting
  • Architectural Lighting
  • Emergency Lighting
  • Industrial Lighting Systems

Conclusion

STMicroelectronics' HVLED815PF represents a blend of performance, efficiency, and versatility, making it a top contender in the field of high-voltage LED drivers. Its robust design and comprehensive feature set ensure that it can meet the demands of a wide array of LED lighting applications, providing designers with a reliable and efficient solution for their lighting needs.
