The M24M01-DFCS6TP/K is a 1 Mbit serial EEPROM from STMicroelectronics, designed to provide robust and efficient non-volatile memory storage. With a 128-byte page write buffer, this device is optimized for advanced data storage solutions in industrial, automotive, and consumer electronics applications.

Key Features

• High Storage Capacity: The M24M01-DFCS6TP/K offers a substantial 1 Mbit (128 Kbytes) of storage, enabling the preservation of significant amounts of data.
• Serial I²C Interface: This EEPROM operates through a fast I²C serial interface, supporting a 400 kHz protocol for quick and efficient communication with microcontrollers and processors.
• Write Cycle Endurance: It has a high write cycle endurance, with the capability to withstand 1 million write cycles, ensuring data integrity over an extended product lifespan.
• Data Retention: With a data retention period of over 40 years, the M24M01-DFCS6TP/K guarantees the longevity of stored information, making it an excellent choice for applications requiring long-term data storage.
• Operating Voltage Range: The device supports a wide operating voltage range from 2.5V to 5.5V, allowing it to be used in various system designs without the need for additional voltage conversion components.
• Temperature Range: It is designed to operate over an extended temperature range from -40°C to +85°C, suitable for demanding environments and ensuring reliable performance under varying conditions.
• Package: The EEPROM comes in an 8-pin TSSOP package, which is known for its compact footprint and suitability for space-constrained applications.

Applications

The M24M01-DFCS6TP/K is versatile and can be employed in a wide array of applications, including:

• Industrial control systems
• Automotive electronics
• Medical devices
• Smart metering
• Consumer electronics
• Portable devices

With its robust design and high reliability, the M24M01-DFCS6TP/K is an excellent choice for designers looking to incorporate a large-capacity EEPROM into their systems.
