Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 630mV @ 3A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 20μA @ 40V
Mounting SMD (SMT)
Case / Package SMC
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 031526-STPS340S
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STPS340S CAD Model

Description

STPS340S - Schottky Rectifier

The STPS340S is a high-efficiency, power Schottky rectifier designed by STMicroelectronics, a leader in semiconductor solutions. This rectifier is specifically engineered to meet the rigorous demands of high-frequency power electronics systems. The STPS340S is well-suited for switch-mode power supplies, converters, free-wheeling diodes, and reverse battery protection applications.

Key Features

  • Low Forward Voltage Drop: The device ensures a low forward voltage drop, which translates to reduced power loss and improved efficiency in applications.
  • High Junction Temperature Capability: With an operating junction temperature range of -40°C to 150°C, the STPS340S is designed to withstand extreme conditions, making it reliable for various industrial applications.
  • Robust Construction: The STPS340S is encapsulated in a DO-214AB (SMC) package, which is known for its compact size and robustness, providing enhanced mechanical strength and thermal resistance.
  • High Surge Current Capability: This rectifier can handle high surge currents, which is essential for applications that experience short-duration overloads.
  • Low Leakage Current: Leakage current is minimized, leading to improved efficiency and reduced standby power consumption.

Applications

  • Switch-mode power supplies (SMPS)
  • DC/DC converters
  • Free-wheeling diodes in converters and motor control circuits
  • Reverse battery protection
  • Power management in portable and battery-powered devices
  • Automotive applications

The STPS340S Schottky rectifier offers a combination of low forward voltage drop and high surge current capability, which makes it an excellent choice for improving the efficiency and reliability of a wide array of power management designs. Its compact footprint and ease of integration make it a preferred choice for engineers looking to optimize their power circuits without compromising on performance or space. With STMicroelectronics' commitment to quality, the STPS340S stands out as a robust and reliable component for your power electronics needs.
