Products specifications

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 3A
Voltage - Forward (Vf) (Max) @ If 840mV @ 3A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 1μA @ 100V
Mounting SMD (SMT)
Case / Package SMBflat
Operating Temperature - Junction 175°C (Max)
Win Source Part Number 126157-STPS3H100UF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STPS3H100UF CAD Model

Description

STPS3H100UF Ultrafast Recovery Diode

The STPS3H100UF from STMicroelectronics is a robust and efficient ultrafast recovery diode, designed to meet the demands of high-performance power supply systems. This diode is part of the ST's power Schottky rectifiers' family, which are known for their low forward voltage drop and reduced leakage current, ensuring energy-efficient operation in a variety of applications.

With a repetitive peak reverse voltage (VRRM) of 100V and an average forward current (IF(AV)) of 3A, the STPS3H100UF is capable of handling moderate power levels while maintaining a low thermal resistance. The device's ultrafast recovery time, typically less than 35ns, makes it an ideal choice for high-frequency power switching, which is critical in minimizing power losses and improving the efficiency of the overall system.

The STPS3H100UF is packaged in a compact and surface-mountable SMB (DO-214AA) package, which not only makes it suitable for automated assembly processes but also helps in saving valuable board space. This package is characterized by its low profile and its ability to handle high surge currents, making it a versatile choice for both compact designs and applications requiring robust surge handling capabilities.

Applications for the STPS3H100UF include switch-mode power supplies (SMPS), high-efficiency DC-DC converters, freewheeling diodes in inverter circuits, and power management systems in consumer electronics. Its fast switching speed also makes it suitable for use in lighting systems, particularly those requiring high-frequency operation such as LED drivers.

STMicroelectronics has ensured that the STPS3H100UF meets the highest quality and reliability standards. The device is RoHS compliant and qualified according to industry standards, making it a safe and environmentally friendly choice for designers and manufacturers looking to create products that meet global regulatory requirements.

In summary, the STPS3H100UF is a high-performance, ultrafast recovery diode that offers low power loss, high efficiency, and reliability in a compact SMB package, making it an excellent choice for a wide range of power management and conversion applications.
