Products specifications

Manufacturer Summit
Win Source Part Number 327770-SMB113AN
Popularity Low
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SMB113AN CAD Model

Description

The SMB113AN is a power management IC (PMIC) manufactured by Summit Microelectronics (now part of Qualcomm). It's designed to provide highly integrated and efficient power conversion for a variety of applications. This PMIC typically integrates multiple voltage regulators, such as buck converters and LDOs, along with control and monitoring features, all within a single chip.

Applications

  • Portable Devices: Powering smartphones, tablets, and other battery-powered devices.
  • Embedded Systems: Supplying power to microcontrollers, processors, and other components in embedded systems.
  • Solid State Drives (SSDs): Managing power for SSD controllers and memory.
  • Wireless Communication Modules: Providing power for Wi-Fi, Bluetooth, and other wireless modules.
  • Industrial Control Systems: Regulating power for sensors, actuators, and other industrial equipment.

Features

  • Multiple Voltage Regulators: Integrates multiple buck converters and LDOs to provide various voltage rails.
  • High Efficiency: Achieves high power conversion efficiency to minimize power loss and extend battery life.
  • Programmable Outputs: Allows flexible configuration of output voltages and current limits.
  • I2C Interface: Enables communication and control via I2C serial interface.
  • Overvoltage Protection: Protects against overvoltage conditions to prevent damage to downstream components.
  • Overtemperature Protection: Shuts down the device in case of excessive temperature to prevent thermal damage.

Benefits

  • Reduced Component Count: Integrates multiple power management functions into a single chip, reducing the number of discrete components.
  • Simplified Design: Simplifies power supply design and reduces board space requirements.
  • Improved Efficiency: Maximizes power conversion efficiency, leading to longer battery life and reduced heat dissipation.
  • Flexible Configuration: Allows customization of output voltages and current limits to meet specific application requirements.
  • Enhanced System Reliability: Provides robust protection features to prevent damage due to overvoltage and overtemperature conditions.
  • Reduced System Cost: Lowers overall system cost by integrating multiple power management functions into a single device.

Additional Details

The SMB113AN typically operates from an input voltage range of 2.7V to 5.5V. The output voltages and current limits of the integrated regulators are programmable via the I2C interface. Key specifications include the switching frequency of the buck converters, the dropout voltage of the LDOs, and the quiescent current of the device. The device is typically packaged in a small QFN package. It is crucial to consult the device datasheet to understand the specific features, capabilities, and limitations of the SMB113AN. Considerations also include thermal management, layout guidelines and component selection.
