The TD1507TR is a monolithic synchronous buck regulator from Techcode, integrating a power MOSFET and a synchronous MOSFET. This device is capable of delivering up to 0.6A of continuous output current from an input voltage range of 4.5V to 28V. It's ideal for applications requiring high efficiency and a small solution size.
Applications:
- Distributed Power Systems: Used in various power distribution architectures.
- Pre-Regulator for Linear Regulators: Can efficiently step down voltage before a linear regulator for improved overall efficiency.
- Battery Chargers: Suitable for charging various battery chemistries, including Lithium-ion and lead-acid.
- Portable Devices: Powering components in devices such as smartphones, tablets, and other handheld electronics.
- FPGA, DSP and MCU supplies.
Features:
- High Efficiency: Synchronous rectification for improved efficiency.
- Adjustable Output Voltage: Allows for flexible voltage settings based on application needs.
- Over-Temperature Protection: Protects the device from thermal damage.
- Current Limit Protection: Prevents overcurrent conditions, enhancing system reliability.
- Input Voltage Range: 4.5V to 28V: Broad input voltage capability for many industrial applications.
- Integrated power MOSFET.
Benefits:
- Increased Efficiency: Minimizes power loss and reduces heat generation, extending battery life.
- Compact Design: Small footprint enables use in space-constrained applications.
- Enhanced Reliability: Protection features ensure stable and reliable operation.
- Cost-Effective: Integrated components reduce the need for external circuitry.
- Simplified Design: Reduces the component count in designs with integrated power MOSFETs and control circuitry.
Additional Details:
The TD1507TR operates at a fixed switching frequency. Its internal compensation network further simplifies the design process, reducing external component count. It provides short-circuit protection and thermal shutdown. Available in SOT23-5 package.
