Products specifications

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 34 Weeks
Manufacturer Texas Instruments
Series 4000B
Package Reel - TR
Operating Temperature Range -55°C ~ 125°C
Mounting Surface Mount
Package 16-SOIC (0.154", 3.90mm Width)
Case / Package 16-SOIC
Family Name CD4044
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 296-31498-2, CD4044BDR-ND, CD4044BDRG4-ND, 296-31498-1, CD4044BDRE4-ND, CD4044BDRE4, 296-31498-6, CD4044BDRG4
Quantity per package 2500
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 866103-CD4044BDR
Ultra Librarian 3D Model Ultra Librarian CD4044BDR CAD Model

Description

The CD4044BDR is a high-quality integrated circuit produced by Texas Instruments, renowned for their innovation and reliability in the semiconductor industry. This particular chip is part of the 4000-series CMOS logic family and features a quad R/S (Reset/Set) latch with 3-state outputs, making it an essential component for a wide range of digital applications.

Key Features

  • Quad R/S Latches: The CD4044BDR contains four independent R/S latches which can be used to store state information. Each latch has separate reset (R) and set (S) inputs.
  • 3-State Outputs: This device offers 3-state output buffers, which can be put into a high-impedance state, effectively disconnecting the output from the circuit. This feature is crucial for bus-oriented systems.
  • Wide Operating Voltage: It operates over a broad voltage range from 3V to 18V, providing versatile power supply compatibility for various applications.
  • Low Power Consumption: Designed with CMOS technology, it ensures low power consumption, which is ideal for battery-operated devices.
  • High Noise Immunity: The inherent characteristics of CMOS technology provide a high degree of noise immunity, safeguarding the device against spurious signals.

Applications

The CD4044BDR is suitable for a multitude of applications, such as:

  • Memory storage circuits
  • Buffer registers
  • Power-on reset control
  • Multiple-bit storage
  • Data transmission systems

Package and Quality

The CD4044BDR is offered in a SOIC-16 (Small Outline Integrated Circuit) package, ensuring a compact footprint for space-conscious designs. Texas Instruments is committed to high standards of quality and reliability, and this product is no exception. It is designed to meet or exceed the stringent requirements of the electronics industry, making it a trusted choice for both commercial and industrial applications.

With its combination of versatile features and reliable performance, the CD4044BDR by Texas Instruments is an excellent choice for designers looking to implement robust latching functions in their digital systems.
