Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Audio Transceiver
Applications Consumer Audio, Musical Instruments
Number of Channels 2
Supply Voltage - Operating 2.9 V to 3.6 V
Temperature Range - Operating -40°C to 85°C (TA)
Specifications 7kHz to 216kHz
Case / Package 48-LQFP (7x7)
Win Source Part Number 026595-PCM9211PTR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PCM9211PTR CAD Model

Description

The PCM9211PTR from Texas Instruments is a sophisticated, high-performance, multifunctional audio processor designed to deliver exceptional sound quality in a wide range of applications.

  • Series: PCM9211
  • Features: 24-bit, 216-kHz, stereo audio codec with a digital audio interface (DIR) and a digital audio driver (DIT)
  • Input/Output: Supports both digital and analog inputs and outputs, including SPDIF, I2S, and DSD
  • PLL: Integrated PLL (Phase Locked Loop) system that can lock to a range of digital audio inputs, offering excellent jitter performance
  • Headphone Amplifier: Built-in headphone amplifier
  • Dynamic Range: 105 dB
  • THD+N: -95 dB
