Products specifications

Categories Discrete Semiconductor Products
Estimated Pruduction Lead Time 31 Weeks
Features Diode Schottky 30 V 200mA Surface Mount 1005/SOD-323F
Manufacturer Comchip Technology
Package Reel - TR
Speed Small Signal =< 200mA (Io), Any Speed
Mounting Surface Mount
Package 1005 (2512 Metric)
Case / Package 1005/SOD-323F
Family Name CDBFR0230
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0070
Other Part Number 641-1208-2, 641-1208-6, 641-1208-1
Quantity per package 4000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 915182-CDBFR0230L
Ultra Librarian 3D Model Ultra Librarian CDBFR0230L CAD Model

Description

The CDBFR0230L is a Fast Recovery Rectifier diode manufactured by Comchip Technology. This diode is designed for applications requiring efficient and fast switching, such as inverters, converters, and power supplies. The fast recovery characteristic reduces switching losses and improves the overall efficiency of the circuit.

Applications

  • Switching Mode Power Supplies (SMPS)
  • Power Factor Correction (PFC) circuits
  • Inverters
  • DC-DC Converters
  • Freewheeling diodes in motor drives

Features

  • Repetitive Peak Reverse Voltage: 300V
  • Average Forward Current: 2A
  • Package Type: SMB (DO-214AA)
  • Fast Reverse Recovery Time: Typically less than 50 ns
  • Low Forward Voltage Drop
  • High Surge Current Capability

Benefits

  • Improved efficiency in power conversion due to fast recovery time.
  • Reduced switching losses in high-frequency applications.
  • Compact size for space-constrained designs.
  • High reliability and long operational life.
  • Easy to mount on PCBs due to its surface-mount package.

Additional Details

The CDBFR0230L features a maximum forward voltage drop of approximately 1.3V at its rated current. The operating temperature range typically spans from -55°C to +150°C. The SMB (DO-214AA) package allows for efficient heat dissipation. It is crucial to refer to the manufacturer's datasheet for precise electrical characteristics, thermal specifications, and soldering guidelines.

This fast recovery rectifier is a crucial component in applications requiring efficient and reliable rectification with fast switching speeds. Its performance and characteristics make it a favored choice in various commercial and industrial applications.
