Products specifications

Manufacturer KEC
Win Source Part Number 1192798-KDS112
Manufacturer Homepage www.keccorp.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian KDS112 CAD Model

Description

The KDS112 is a Schottky Barrier Diode manufactured by KEC. Schottky diodes are known for their fast switching speeds and low forward voltage drop, making them suitable for high-frequency applications and circuits requiring efficient rectification.

Applications:

  • High-Frequency Rectification: Rectifying signals in high-frequency circuits.
  • Switching Power Supplies: Improving efficiency in switching power supplies.
  • Reverse Polarity Protection: Protecting circuits from reverse polarity connections.
  • Voltage Clamping: Clamping voltage levels to protect sensitive components.
  • Mixers and Detectors: Used in mixers and detectors for signal processing.

Features:

  • Low Forward Voltage Drop: Minimizes power losses and improves efficiency.
  • Fast Switching Speed: Enables efficient operation in high-frequency circuits.
  • Small Package Size: Available in small packages for space-constrained applications.
  • Low Reverse Leakage Current: Minimizes leakage current and improves performance.

Benefits:

  • Improved Efficiency: Low forward voltage drop and fast switching speed improve circuit efficiency.
  • Compact Design: Small package size allows for use in portable devices.
  • Reliable Operation: Designed for reliable performance in various applications.

Additional Details:

Without a specific datasheet, the KDS112 is likely characterized by parameters such as its forward voltage drop (VF), reverse voltage (VR), forward current (IF), and reverse recovery time (trr). Typical Schottky diodes have a forward voltage drop in the range of 0.2V to 0.5V and a fast reverse recovery time. The specific voltage and current ratings would determine its suitability for different applications. The package is likely a small surface-mount package such as SOD-323 or SOD-123.
