5220 Schurter Inc.
Same model may have multiple batches, images only for reference.

5220

Part No 5220
Manufacturer Keystone Electronics
Catalog Battery Holders, Clips, Contacts
Description BATT CNTCT SPRING MULTI SLDR LUG
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Battery Products - Battery Holders, Clips, Contacts
Mfr Keystone Electronics
Package Bulk
Product Status Active
Battery Type, Function Cylindrical, Contact (Single)
Style Contact Spring (Coil)
Battery Cell Size Multiple
Mounting Type Custom
Termination Style Solder Lug
Standard Package 100 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 546385-5220
Ultra Librarian 3D Model Ultra Librarian 5220 CAD Model

Description

The Keystone Electronics 546385-5220 is a battery holder, clip, and contact product in the category of battery products.

  • Termination Style: solder lug
  • Holder Style: contact spring (coil) style holder is designed for cylindrical batteries with a single contact.
  • Mounting Type: custom
  • ECCN: EAR99, indicating that it does not require an export license.
  • MSL Level: 1, meaning it has an unlimited shelf life.
  • REACH Status: unaffected, complying with the REACH regulations.
  • HTSUS Code: 8536.69.4040
  • Manufacturer: Keystone Electronics and is currently active in the market.
