Products specifications

Manufacturer Linear Technology
Win Source Part Number 1206668-LT3437IDD
Manufacturer Homepage www.linear.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LT3437IDD CAD Model

Description

Product Overview: LT3437IDD from Linear Technology

The LT3437IDD is a high-performance, step-down switching regulator from Linear Technology, a leader in analog integrated circuits. This device is designed to manage power efficiently and reliably, making it an ideal solution for a wide range of applications, including automotive, industrial, and portable devices.

Key Features

  • Wide Input Voltage Range: The LT3437IDD operates from an input voltage range of 3.3V to 60V, making it versatile for use in systems with varying power supplies.
  • Adjustable Output Voltage: Users can adjust the output voltage from 1.25V to the input voltage, allowing for a high level of flexibility in different circuit designs.
  • High Efficiency: With a switch operating up to 200kHz, the LT3437IDD can maintain high efficiency, which is crucial for reducing heat and increasing battery life in portable applications.
  • Low Dropout Operation: The regulator's low dropout performance ensures continued operation even as the input voltage approaches the output voltage, which is essential for battery-powered applications.
  • Thermal Protection: The device includes thermal shutdown protection that safeguards the circuit from damage due to excessive heat.
  • No Schottky Diode Required: The LT3437IDD incorporates an internal switch, eliminating the need for an external Schottky diode and simplifying the design.

Applications

The LT3437IDD's robust feature set makes it suitable for a variety of applications, including but not limited to:

  • Automotive electronics
  • Industrial power systems
  • Portable instruments
  • Telecommunications equipment
  • Power supplies for battery-operated devices

Package Information

The LT3437IDD is available in a compact 8-lead DFN package, which is designed for space-constrained applications. This package also offers excellent thermal performance, ensuring reliable operation even in environments with limited airflow.

Quality and Reliability

Linear Technology is known for its commitment to quality, and the LT3437IDD is no exception. It is built to meet high standards of reliability and performance, ensuring that it can withstand the rigors of real-world applications. Customers can trust in the Linear Technology brand for their power management needs.
