Products specifications

Manufacturer Linear Technology
Win Source Part Number 1206736-LT3505EMS8E
Manufacturer Homepage www.linear.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LT3505EMS8E CAD Model

Description

Linear Technology's LT3505EMS8E: A Compact, Efficient Power Solution

The LT3505EMS8E is a versatile and powerful DC/DC converter from Linear Technology, designed to cater to a broad range of power supply requirements. This high-performance component is engineered to deliver efficiency and reliability in a compact MSOP-8 package, making it an ideal choice for space-constrained applications.

Efficient Power Conversion

With an input voltage range of 3V to 40V, the LT3505EMS8E is capable of operating in a variety of supply conditions, ensuring consistent performance even under fluctuating input voltages. This makes it particularly suitable for automotive and industrial power systems where input voltages can vary significantly.

Robust Output Capabilities

The device is designed to provide a fixed output voltage of 5V, with an output current capability of up to 500mA. This is sufficient to power a wide array of electronic devices and circuits, from microcontrollers and sensors to communication modules.

Advanced Features

The LT3505EMS8E incorporates a range of features that enhance its performance and ease of use:

  • Internal 1.1A Switch: The built-in switch can handle peak currents up to 1.1A, allowing for a simple and efficient design without the need for external power components.
  • Burst Mode® Operation: This feature ensures high efficiency at low output currents, which is essential for battery-powered applications to extend battery life.
  • Frequency Foldback and Thermal Protection: These mechanisms protect the device under overload conditions, ensuring reliability and longevity of the power supply circuit.
  • Low Shutdown Current: The shutdown feature reduces the current draw to less than 1µA, which is critical for power conservation in battery-operated systems.

Applications

The LT3505EMS8E is suitable for a multitude of applications, including but not limited to:

  • Portable Instruments
  • Automotive Power Supplies
  • Industrial Power Systems
  • Battery-Powered Equipment
  • Point-of-Load Power Supplies

Overall, the LT3505EMS8E from Linear Technology is a compact, efficient, and reliable solution for modern electronic power supply challenges. Its robust design and advanced features make it a top choice for engineers and designers looking to optimize their power management systems.
