Products specifications

Categories Sensors, Transducers
Manufacturer Linear Technology
Packaging Reel package
Sensor Type Analog, Local/Remote
Sensing Temperature - Local 0°C ~ 70°C
Sensing Temperature - Remote 0°C ~ 70°C
Output Type Analog Voltage
Operating Supply Voltage 2.5 V ~ 5.5 V
Resolution 4mV/°C
Accuracy - Highest (Lowest) ±1.5°C
Test Condition 25°C
Operating Temperature Range 0°C ~ 70°C
Mounting SMD
Package 6-WFDFN Exposed Pad
Manufacturer Package 6-DFN (2x3)
Win Source Part Number 783208-LTC2997CDCB#TRMPBF
Popularity Medium
Supply and Demand Status Limited
Family Name LTC2997
Introduction Date July 07, 2011
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LTC2997CDCB#TRMPBF CAD Model

Description

The LTC2997CDCB#TRMPBF is a high-precision temperature-to-digital converter from Linear Technology that provides a direct temperature output by measuring the voltage across a diode-connected transistor. This product is part of Linear Technology's extensive range of temperature sensors and monitoring devices designed for various applications including system thermal control, environmental monitoring, and industrial process control.

Key Features

  • Precision Temperature Sensing: The LTC2997 offers accurate temperature sensing with a resolution of 0.1°C and an accuracy of ±1°C, ensuring reliable and precise temperature readings for critical applications.
  • Wide Temperature Range: This device is capable of measuring temperatures from -40°C to 125°C, making it versatile for a broad range of environments and applications.
  • Easy Integration: With a simple three-pin interface, the LTC2997 can be easily integrated into existing systems, requiring minimal additional components and simplifying design complexity.
  • No Calibration Required: The device is factory calibrated and does not require any additional calibration, which saves time and resources during system setup and maintenance.
  • Low Supply Voltage: It operates from a supply voltage as low as 2.7V, making it suitable for battery-powered and portable applications.
  • I2C Interface: The built-in I2C interface allows for easy communication with microcontrollers and other digital systems, facilitating system integration and data retrieval.

Applications

The LTC2997CDCB#TRMPBF is ideal for a variety of applications that require accurate and reliable temperature measurements. These include:

  • Computer System Cooling
  • Environmental Monitoring Systems
  • Industrial Process Control
  • Battery Management Systems
  • Automotive and Aerospace Systems

Overall, the LTC2997CDCB#TRMPBF temperature-to-digital converter is a robust and reliable solution for designers looking to incorporate precise temperature monitoring into their systems. Its ease of use, coupled with its high accuracy and low power consumption, makes it an excellent choice for a wide array of temperature sensing applications.
