Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 70mV
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 020670-LTC485CS8#TRPBF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LTC485CS8#TRPBF CAD Model

Description

Product Overview: LTC485CS8#TRPBF

The LTC485CS8#TRPBF is a low power differential bus transceiver designed by Linear Technology for multipoint data transmission standard RS485 applications. It is crafted to provide balanced data transmission lines for long-distance and noise-immune data communication, making it an ideal choice for industrial control systems, networked devices, and other applications requiring robust serial communication.

Key Features

  • Low Power Operation: The device operates with very low power consumption, making it suitable for power-sensitive applications.
  • High Data Rates: It supports data rates up to 2.5Mbps, enabling fast data transmission for time-critical operations.
  • Single 5V Supply: The LTC485CS8#TRPBF operates on a single 5V supply, simplifying power supply design and reducing system complexity.
  • Thermal Shutdown Protection: The built-in thermal shutdown protection ensures that the device is protected from damage due to overheating.
  • Driver and Receiver Enable: Separate enable pins for the driver and receiver provide additional control and help to reduce power consumption when the transceiver is not in active use.
  • Failsafe Receiver: The receiver has a failsafe feature that guarantees a known output if the input is open or shorted.

Applications

  • Industrial Control Systems
  • Networked Devices
  • Data Acquisition Systems
  • Packet Switched Networks
  • Telecommunications Equipment

Package and Quality

The LTC485CS8#TRPBF comes in an 8-lead SOIC package, which is compact and suitable for space-constrained applications. The product is available in tape and reel packaging (denoted by the #TRPBF suffix), facilitating automated assembly processes for high-volume production. Linear Technology ensures high-quality standards, and the LTC485CS8#TRPBF is designed to meet or exceed the stringent requirements of industrial applications.

Conclusion

In summary, the LTC485CS8#TRPBF from Linear Technology is a high-performance RS485 transceiver that combines low power consumption with high data rate capabilities. Its robust feature set and compact packaging make it an excellent choice for designers looking to implement reliable and efficient data communication in their systems.
