KMB16F PACELEADER INDUSTRIAL
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr MDD
Series MBF
Package Tape & Reel
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 60 V
Current - Average Rectified (Io) 41 mA
Voltage - Forward (Vf) (Max) @ If 700 mV @ 1 A
Current - Reverse Leakage @ Vr 300 mA @ 60 V
Temperature Range - Operating -55°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case 4-SMD, Flat Leads
Supplier Device Package MBF
Standard Package 5,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 610587-KMB16F
Ultra Librarian 3D Model Ultra Librarian KMB16F CAD Model

Description

The 610587-KMB16F is a single phase bridge rectifier diode designed for standard applications.

  • Series: MBF
  • Packaging: Tape and Reel
  • Average Rectified Current: 41mA
  • Forward Voltage: 700mV @ 1A
  • Peak Reverse Voltage: 60V
  • Reverse Leakage Current: 300mA @ 60V
  • Mounting: Surface Mountable
  • Operating Temperature: -55°C to 125°C
