RS2MB PACELEADER INDUSTRIAL
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr MDD
Series SMB
Package Tape & Reel
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 1000 V
Current - Average Rectified (Io) 2A
Voltage - Forward (Vf) (Max) @ If 1.3 V @ 2 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 500 ns
Current - Reverse Leakage @ Vr 5 µA @ 1000 V
Capacitance @ Vr, F 50pF @ 4V, 1MHz
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Supplier Device Package SMB
Operating Temperature - Junction -55°C ~ 150°C
Standard Package 12,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 661173-RS2MB
Ultra Librarian 3D Model Ultra Librarian RS2MB CAD Model

Description

The MDD 661173-RS2MB electronic component is a fast recovery diode suitable for rectifier applications.

  • Series: SMB
  • Package: Tape & reel
  • Pieces Per Package: 12,000
  • Maximum DC Reverse Voltage: 1000V
  • Average Rectified Current: 2A
  • Recovery Time: Fast, less than 500ns
  • Reverse Leakage Current: 5µA @ 1000V
  • Category: Diodes - rectifiers - single diodes
  • Product Status: Active
  • Manufacturer: MDD
  • Win Source Part Number: 661173-RS2MB
