Products specifications

Category Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr Microchip Technology
Package Bulk
Product Status Active
Voltage - Zener (Nom) (Vz) 12 V
Tolerance ±5%
Power - Max 500 mW
Impedance (Max) (Zzt) 30 Ohms
Current - Reverse Leakage @ Vr 1 µA @ 8.7 V
Voltage - Forward (Vf) (Max) @ If 1.5 V @ 200 mA
Temperature Range - Operating -65°C ~ 175°C (TJ)
Mounting Type Through Hole
Package / Case DO-204AH, DO-35, Axial
Supplier Device Package DO-35 (DO-204AH)
Standard Package 1 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0050
Win Source Part Number 539190-1N5242
Ultra Librarian 3D Model Ultra Librarian 1N5242 CAD Model

Description

The 1N5242 is a reliable Zener diode from the renowned manufacturer, Microchip Technology. This component is designed to provide precise voltage regulation, making it an ideal choice for a wide range of electronic applications. The 1N5242 Zener diode offers a nominal Zener voltage of 12V, which is particularly suitable for stabilizing voltage and protecting circuits from overvoltage conditions.

With its power dissipation of 500mW, the 1N5242 is capable of handling moderate power levels while maintaining its voltage regulation capabilities. This makes it a versatile component for use in power supply circuits, voltage reference applications, and as a surge protector in sensitive electronics.

The 1N5242 comes in a DO-35 package, a small and durable glass-body package that is well-suited for through-hole mounting on printed circuit boards. Its compact size ensures that it can be easily integrated into various designs without taking up significant space, which is particularly beneficial for compact electronic devices.

One of the key features of the 1N5242 is its tight Zener voltage tolerance. This specification ensures consistent performance and reliable operation across different devices and applications. The diode also has a low dynamic impedance, which contributes to its stable voltage regulation even under varying load conditions.

Microchip Technology's commitment to quality is evident in the 1N5242, which is manufactured to high standards to ensure longevity and consistent performance. Whether used in industrial, commercial, or consumer electronics, the 1N5242 Zener diode is an excellent choice for designers who require a dependable voltage regulator in their circuits.

In summary, the 1N5242 Zener diode from Microchip Technology is a compact, efficient, and reliable solution for voltage regulation needs. It is a testament to Microchip's reputation for producing high-quality electronic components that meet the demands of a wide range of applications.
