Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Purpose Step-Up
Topology Charge Pump
Output Type Fixed
Number of Outputs 1
Minimum Input Voltage 1.8V
Maximum Input Voltage 3.6V
Nominal Output Voltage (Min/Fixed) 3.3V
Output Current 100mA
Frequency - Switching 650kHz
Synchronous Rectifier No
Temperature Range - Operating -40°C to 125°C (TJ)
Mounting SMD (SMT)
Case / Package 10-DFN (3x3)
Win Source Part Number 1074681-MCP1257-E/MF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MCP1257-E/MF CAD Model

Description

Product Overview: MCP1257-E/MF from Microchip Technology

The MCP1257-E/MF is a high-performance, low-noise, regulated charge pump DC-DC converter manufactured by Microchip Technology. This efficient and versatile component is designed to provide a stable and reliable power supply for battery-powered and low-power applications. The MCP1257-E/MF stands out for its compact surface-mount package and the ability to operate with minimal external components, making it an ideal solution for space-constrained designs.

Key Features

  • Output Voltage: The device offers a fixed output voltage of 5V, which is ideal for powering microcontrollers and other digital logic circuits that require a stable 5V supply.
  • High Efficiency: With its charge pump technology, the MCP1257-E/MF can deliver high efficiency across a wide range of input voltages, ensuring optimal performance and extended battery life in portable applications.
  • Low Ripple Voltage: The device is engineered to produce a low output voltage ripple, which is critical for sensitive analog and RF circuitry, minimizing noise and interference.
  • Thermal Protection: It includes thermal shutdown protection, which safeguards the device and the system it powers from potential damage due to excessive heat.
  • Low Quiescent Current: The MCP1257-E/MF boasts a low quiescent current, which significantly reduces power consumption when the device is in standby mode, making it suitable for battery-powered applications where power conservation is crucial.

Applications

The MCP1257-E/MF is designed for a wide range of applications, including but not limited to:

  • Portable electronic devices
  • Handheld medical equipment
  • Wireless sensors and transmitters
  • Power supplies for microcontrollers and digital logic
  • Backup power supplies

Package and Quality

This device is available in an 8-lead MSOP (Micro Small Outline Package) that offers a compact footprint for space-sensitive applications. Microchip Technology's commitment to quality ensures that the MCP1257-E/MF meets stringent industry standards for reliability and performance.
