Products specifications

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Active
Core Processor PIC
Part Core Size 8-Bit
Speed(Frequency) 8MHz
Number of I/O 4
Program Memory Size 384B (256 x 12)
Program Memory Type FLASH
Data RAM Size 16 x 8
Supply Voltage - Operating 2 V to 5.5 V
Data Converters A/D 2x8b
Temperature Range - Operating -40°C to 125°C (TA)
Case / Package 8-DFN (2x3)
Win Source Part Number 1088124-PIC10F220-E/MC
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PIC10F220-E/MC CAD Model

Description

Microchip Technology's PIC10F220-E/MC Microcontroller

The PIC10F220-E/MC is a powerful and versatile microcontroller (MCU) designed and manufactured by Microchip Technology, a leading provider of smart, connected, and secure embedded control solutions. This particular MCU is part of the PIC10F family, which is renowned for its compact form factor and efficient performance in a variety of applications.

With a 6-pin SMD (Surface Mount Device) package, the PIC10F220-E/MC is an ideal choice for space-constrained applications. Despite its small size, this MCU packs a robust set of features that make it suitable for a wide range of uses, from simple timing operations to more complex system controls.

At its core, the PIC10F220-E/MC operates with a 12-bit instruction set and a precision 8 MHz internal oscillator, providing users with a stable and reliable processing speed without the need for external clock components. This microcontroller also includes 256 bytes of Flash program memory and 16 bytes of data RAM, which, while modest, are sufficient for numerous low-power and small-scale applications.

One of the standout features of the PIC10F220-E/MC is its programmable 8-bit analog-to-digital converter (ADC), which allows for the interfacing with analog sensors and the conversion of analog signals to digital data for processing. This feature is particularly useful in applications that require environmental monitoring, such as temperature or light sensing.

Additionally, the PIC10F220-E/MC offers two I/O pins, which can be configured for various input/output functions. These pins provide the necessary interfaces for controlling external devices or for receiving input signals. The MCU also includes a comparator module, which can be used in applications that require voltage level detection or decision-making capabilities based on analog inputs.

Designed with power efficiency in mind, the PIC10F220-E/MC supports a wide operating voltage range of 2.0V to 5.5V, making it adaptable to various power supply conditions. Its power-saving Sleep mode further extends the battery life of portable and remote applications.

Overall, the PIC10F220-E/MC by Microchip Technology is a compact, feature-rich microcontroller that offers an excellent balance of performance and power consumption for designers looking to optimize their embedded systems.
