Products specifications

Category Discrete Semiconductor Products
Family Diodes,Rectifiers - Arrays
Manufacturer NXP
Win Source Part Number 231651-BAT54S
Family Name BAT54S
Introduction Date April 01, 1992
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Signal Processing
Package Tape & Reel (TR);Cut Tape (CT)
Product Status Active
Diode Configuration 1 Pair Series Connection
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) (per Diode) 100mA
Voltage - Forward (Vf) (Max) @ If 1V @ 100mA
Speed Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr) 5ns
Current - Reverse Leakage @ Vr 2µA @ 25V
Operating Temperature - Junction -40°C ~ 125°C
Grade -
Mounting Type Surface Mount
Package / Case TO-236-3, SC-59, SOT-23-3
Supplier Device Package SOT-23
Ultra Librarian 3D Model Ultra Librarian BAT54S CAD Model

Description

The BAT54S, manufactured by NXP Semiconductors, is a high-efficiency, surface-mounted Schottky barrier diode designed for applications requiring fast switching and low power loss. This diode is encapsulated in a small SOT-23 plastic package, making it a suitable choice for compact circuit designs where space is at a premium.

Key Features

  • Low Forward Voltage Drop: The BAT54S features a low forward voltage drop, which enhances its efficiency in applications by minimizing power loss during conduction.
  • Fast Switching Speed: With its Schottky barrier design, the BAT54S offers fast switching capabilities, making it ideal for high-frequency operations and minimizing switching losses.
  • Low Capacitance: The diode's low capacitance allows for better performance in high-speed switching applications and reduces noise in signal processing.
  • Surface-Mount Package: The SOT-23 package is designed for automated assembly processes, and its small form factor is well-suited for densely packed PCBs.
  • High Surge Current Capability: The BAT54S can handle high surge currents, offering robust performance during transient conditions.

Applications

The BAT54S is versatile and can be used in a variety of applications, including:

  • Power supply circuits
  • DC-DC converters
  • Reverse polarity protection circuits
  • Low voltage rectification
  • High-speed switching circuits
  • Signal demodulation

Electrical Characteristics

The BAT54S has a continuous reverse voltage of 30 volts and a forward current of 200 mA. Its peak forward surge current is 600 mA, and it operates within a junction temperature range of -55°C to +125°C, making it suitable for a wide range of environmental conditions.

Quality and Reliability

NXP Semiconductors is known for its commitment to quality and reliability, and the BAT54S is no exception. It is produced in facilities that comply with rigorous industry standards, ensuring that each diode meets the highest quality benchmarks before it reaches customers.
