LPC2136FBD64

Part No LPC2136FBD64
Manufacturer NXP / Nexperia
Description Single-chip 16/32-bit microcontrollers; 32/64/512 kB ISP/IAP Flash with 10-bit ADC and DAC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer NXP
Win Source Part Number 1204138-LPC2136FBD64
Manufacturer Homepage www.nxp.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LPC2136FBD64 CAD Model

Description

The NXP LPC2136FBD64 is a robust microcontroller that is part of the LPC2100 series, designed to cater to a wide range of embedded applications. This microcontroller is built on a 32-bit ARM7TDMI-S CPU core, which ensures efficient processing and control tasks. It operates at a maximum frequency of 60 MHz, providing a balance between power consumption and performance.

Key Features:

  • Memory: The LPC2136FBD64 comes with 256 KB of on-chip Flash memory for program storage and 16 KB of SRAM, which is more than sufficient for handling complex code and data buffering.
  • I/O Ports: It is equipped with multiple 32-bit timers, an assortment of I/O ports, and up to 47 general-purpose I/O pins, making it highly flexible for interfacing with various peripherals.
  • Connectivity: This microcontroller supports multiple serial communication interfaces, including two UARTs, two Fast I2C-bus interfaces, SPI, and SSP with buffering and variable data length capabilities.
  • ADC: It features a 10-bit Analog-to-Digital Converter (ADC) with up to 14 channels, allowing for accurate analog signal measurement and conversion.
  • PWM: The device is capable of producing multiple Pulse Width Modulation (PWM) signals which are essential for motor control and other applications requiring precise timing control.
  • System Control: The LPC2136FBD64 includes a system control block for power control, clock control, and system peripherals reset.
  • Package: It is available in a compact 64-pin LQFP package, which is ideal for space-constrained applications.
  • Power Management: The microcontroller supports multiple power-saving modes, enabling the design of energy-efficient applications.

Applications:

The NXP LPC2136FBD64 is suitable for a diverse range of applications, including industrial control systems, medical instruments, automotive electronics, and communication devices. Its robust feature set also makes it an excellent choice for complex tasks such as embedded networking, motor control, and real-time data processing.

With its high level of integration and flexibility, the LPC2136FBD64 is a go-to microcontroller for designers looking for a reliable and powerful solution for their embedded projects.
