Products specifications

Manufacturer NXP
Win Source Part Number 1238944-PMEG2005EB
Manufacturer Homepage www.nxp.com
Family Name PMEG2005EB
Introduction Date December 30, 2002
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PMEG2005EB CAD Model

Description

The NXP PMEG2005EB is a highly efficient, low voltage drop Schottky barrier rectifier diode designed for a variety of applications that demand high efficiency and fast switching performance. This robust component is encapsulated in a small SOD-523 (SC-79) surface-mounted device (SMD) package, which makes it suitable for high-density circuit designs.

Key Features

  • Low Forward Voltage: The PMEG2005EB offers a low forward voltage drop, typically just 0.37V at IF of 1A, which contributes to reduced power loss and improved energy efficiency in your circuit designs.
  • High Forward Current: With a maximum average forward current of 2A, this diode is capable of handling significant current, making it ideal for power regulation and conversion applications.
  • Reverse Voltage: It can withstand a peak repetitive reverse voltage of up to 20V, ensuring reliability and stability in operation.
  • Fast Switching: The PMEG2005EB is characterized by its fast switching capability, which is essential for applications requiring high-frequency operation.
  • Low Reverse Leakage Current: The diode has a low leakage current, which minimizes power waste when in the reverse-biased condition.
  • Thermal Performance: It offers excellent thermal performance due to its small package size and power dissipation capacity, making it suitable for compact electronic assemblies.

Applications

The PMEG2005EB is ideal for a range of applications, including but not limited to:

  • Switching power supplies
  • DC-DC converters
  • Power management devices
  • Reverse polarity protection circuits
  • Low voltage, high frequency inverters
  • Free-wheeling diodes in converters and motor control circuits

Product Summary

The NXP PMEG2005EB is a versatile Schottky barrier rectifier that offers designers a combination of low forward voltage drop, high forward current capability, and fast switching speeds in a compact package. Whether you're developing power supply units, portable devices, or automotive electronics, the PMEG2005EB provides reliable and efficient performance for your rectification needs.
