Products specifications

Category Uncategorized - Unclassified
Mfr onsemi
Series -
Package Tape & Reel
Product Status Obsolete
Base Product Number DAN222
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 1367327-DAN222
Ultra Librarian 3D Model Ultra Librarian DAN222 CAD Model

Description

The ON Semiconductor DAN222 is a high-performance, dual switching diode designed to meet the needs of a wide range of electronic applications. This small signal diode is optimized for low power consumption and high efficiency, making it an ideal choice for portable and battery-powered devices.

Key Features

  • Dual Diode Configuration: The DAN222 contains two independent diodes in a single package, enabling the design of compact circuits without sacrificing performance.
  • Low Forward Voltage: With a low forward voltage drop, this diode ensures minimal power loss and improved system efficiency, which is critical for power-sensitive designs.
  • Fast Switching Speed: The diode's fast switching capability allows for efficient operation in high-frequency applications, reducing switching losses and improving overall performance.
  • High Reliability: Built with ON Semiconductor's rigorous quality standards, the DAN222 offers excellent reliability and stability over its operational lifespan.
  • Surface Mount Package: The SOT-23 package is suitable for automated assembly processes and helps in reducing the overall size of the circuit board.

Applications

The versatility of the ON Semiconductor DAN222 makes it suitable for a variety of applications, including:

  • High-speed switching circuits
  • Voltage clamping
  • Protection circuits
  • Logic systems
  • DC-DC converters

Technical Specifications

Parameter Value Package Type SOT-23 Configuration Dual Common Anode Peak Repetitive Reverse Voltage 80 V Continuous Forward Current 100 mA Forward Voltage 1.0 V @ 10 mA Reverse Recovery Time 4 ns

The ON Semiconductor DAN222 is a testament to the company's commitment to providing high-quality, reliable components for the electronics industry. Whether you're designing a new product or optimizing an existing one, the DAN222 offers the performance and dependability that engineers have come to expect from ON Semiconductor.
