DB202S HY ELECTRONIC CORP.
Same model may have multiple batches, images only for reference.

DB202S

Part No DB202S
Manufacturer Rectron USA
Catalog Bridge Rectifiers
Description BRIDGE RECT 100V 2A DB-S
Datasheet
DB202S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr Rectron USA
Package Tape & Reel
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 100 V
Current - Average Rectified (Io) 2 A
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 2 A
Current - Reverse Leakage @ Vr 5 µA @ 100 V
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case 4-SMD, Gull Wing
Supplier Device Package DB-S
Standard Package 8,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 584112-DB202S
Ultra Librarian 3D Model Ultra Librarian DB202S CAD Model

Description

The 584112-DB202S is a single phase bridge rectifier used in discrete semiconductor products.

  • Average Rectified Current (Io): 2A
  • Forward Voltage (Vf): 1.1V @ 2A
  • Reverse Leakage Current: 5 μA @ 100V
  • Peak Reverse Voltage: 100V
  • Mounting Type: Surface Mount
  • Package: 4-SMD, Gull Wing
  • Operating Temperature Range: -55°C to 150°C
  • Manufacturer: Rectron USA
  • Status: Active
