The PCFM12JT47R0 is a thick film chip resistor manufactured by Stackpole Electronics Inc. It is designed for general purpose applications and offers reliable performance in a compact size. Chip resistors like the PCFM12JT47R0 are widely used in electronic circuits for current limiting, voltage division, and pull-up/pull-down resistor configurations.

Applications

• Consumer electronics (e.g., smartphones, tablets, laptops)
• Industrial control systems
• Power supplies
• Automotive electronics
• Medical devices

Features

• Thick film technology
• Surface mount design
• High reliability
• Compact size (1206 package)
• 47 Ohm resistance
• 5% tolerance
• 1/4W power rating

Benefits

• Provides precise resistance value in electronic circuits
• Easy to integrate into automated assembly processes
• Offers stable performance over a wide range of temperatures
• Reduces board space requirements due to its small size
• Cost-effective solution for general purpose resistor applications

Additional Details

The PCFM12JT47R0 resistor conforms to the 1206 EIA standard size. This means it has a length of 0.126 inches (3.2 mm) and a width of 0.063 inches (1.6 mm). It is a lead-free component and RoHS compliant, making it suitable for environmentally conscious designs. The resistor has a temperature coefficient of resistance (TCR) of ±200 ppm/°C, indicating the change in resistance value with temperature variations. The operating temperature range is typically from -55°C to +155°C. This resistor is suitable for reflow soldering processes. The part number indicates a resistance value of 47 Ohms, with a tolerance of 5%. The “JT” designates the tolerance code and packaging type. It's commonly mounted on PCBs using solder paste and reflow soldering techniques.
