Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tube
Status Obsolete
Output Type Fixed
Voltage - Input (Maximum) 35V
Min/Fixed Output Voltage 5V
Maximum Dropout Voltage 2V at 1A
Output Current 1.5A
Current - Quiescent (Iq) 6mA
PSRR 68dB (120Hz)
Protection Features Over Temperature, Short Circuit
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Supplier Device Package D2PAK
Family Part Number L7805
Manufacturer Pack Quantity 1,000
MSL Level 1 (Unlimited)
Win Source Part Number 1194494-L7805ABD2T
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Power Management
Ultra Librarian 3D Model Ultra Librarian L7805ABD2T CAD Model

Description

STMicroelectronics L7805ABD2T Voltage Regulator

The L7805ABD2T is a robust linear voltage regulator designed and manufactured by STMicroelectronics, a global semiconductor leader. This device is part of the popular L78 series, which is renowned for its reliability and efficiency in providing stable output voltages. The L7805ABD2T specifically offers a fixed output voltage of 5V, which is commonly needed in a wide range of electronic applications.

With its ability to deliver up to 1.5A of output current, this voltage regulator is suitable for powering small to medium-sized devices. It is designed to work with an input voltage range from 7V to 35V, offering a great deal of flexibility for various power supply configurations. This makes the L7805ABD2T an excellent choice for projects that require a consistent 5V power supply, such as microcontroller circuits, LED lighting, and other digital devices.

The L7805ABD2T comes in a D2PAK package, which is known for its high power dissipation capability. This package is ideal for surface-mount technology (SMT), allowing for efficient assembly and space-saving design on printed circuit boards (PCBs). The thermal overload protection and short-circuit protection features of the L7805ABD2T ensure that your circuits are safeguarded against excessive heat and current, enhancing the longevity of both the regulator and the connected components.

Additional features of the L7805ABD2T include low dropout voltage, which ensures the regulator remains functional even when the input-to-output voltage differential is minimal. This is particularly useful in battery-powered applications where preserving energy is crucial. Moreover, the regulator has a low quiescent current, further contributing to the overall energy efficiency of the system it powers.

In summary, the STMicroelectronics L7805ABD2T is a dependable and efficient solution for applications requiring a stable 5V power supply. Its robust design, coupled with protection features and energy-efficient operation, makes it a go-to voltage regulator for designers and hobbyists alike.
