STMicroelectronics LD1117S12TR Voltage Regulator

The LD1117S12TR from STMicroelectronics is a robust and reliable low-dropout (LDO) voltage regulator designed to offer a stable 1.2V output voltage. This component is an excellent choice for applications requiring a regulated power supply with a low voltage drop and good noise immunity. The LD1117S12TR is capable of delivering up to 800mA of output current, making it suitable for a wide range of electronic devices.

The device comes in a compact SOT-223 package, which is not only space-saving but also ensures good thermal performance. This package allows the LD1117S12TR to operate at a junction temperature range from -40°C to 125°C, providing reliable performance even under harsh environmental conditions.

One of the key features of the LD1117S12TR is its low dropout voltage, which ensures efficiency by minimizing the difference between the input and output voltages. This characteristic is particularly important in battery-powered applications where maximizing battery life is crucial. Furthermore, the device includes current and thermal limit protections, which safeguard the voltage regulator and the downstream circuitry from potential damage caused by excessive current or overheating.

The LD1117S12TR is also versatile in its application, supporting adjustable versions with an external pair of resistors. This allows designers to set the output voltage to a desired value within a specific range, providing flexibility for various design requirements. Additionally, the device exhibits low ground current characteristics, which further contribute to its overall efficiency.

To ensure a stable output voltage, the LD1117S12TR typically requires a minimum load capacitance of 10µF, although this value may vary depending on the specific application conditions. The device is also characterized by its low output noise, which makes it an excellent choice for noise-sensitive applications such as RF circuits and precision instrumentation.

In summary, the STMicroelectronics LD1117S12TR is a high-performance LDO voltage regulator that offers a cost-effective solution for a variety of applications requiring a stable and efficient power supply.
