Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 4
Slew Rate 0.4 V/μs
Gain Bandwidth Product (GBP) 1.3MHz
Current - Input Bias 20nA
Voltage - Input Offset 2mV
Operating Supply Current 1.5mA
Channel Output Current 70mA
Supply Voltage - Operating 3 V to 30 V, ±1.5 V to 15 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 14-SO
Win Source Part Number 019073-LM324DT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Industrial
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian LM324DT CAD Model

Description

The LM324DT from STMicroelectronics is a versatile and widely-used operational amplifier (op-amp) that comes in a 14-pin SOIC package. This device is part of the LM324 series, which is known for its low power consumption and high stability, making it suitable for a vast array of electronic applications.

Key Features

  • Low Power Consumption: The LM324DT is designed for battery-powered and energy-efficient applications, ensuring minimal power usage without sacrificing performance.
  • Wide Gain Bandwidth: With a gain bandwidth product of 1.2 MHz, this op-amp is capable of handling a broad range of frequencies, making it ideal for audio processing, filtering, and signal conditioning.
  • Large Output Voltage Swing: The output can swing close to the supply rails, which maximizes the dynamic range in single-supply operations.
  • Low Input Bias Current: This characteristic is crucial for high-impedance sensor interfaces and precision applications, ensuring accuracy and consistency.
  • Input Common-Mode Voltage Range Includes Ground: This feature allows for direct sensing near ground, which is particularly useful in single-supply operations.
  • Four Internally Compensated Op Amps: The quad configuration simplifies designs by providing four op-amps in one package, saving space and reducing component count.

Applications

The LM324DT is suited for a wide range of applications, including:

  • Transducer amplifiers
  • DC gain blocks
  • All the conventional op-amp circuits
  • Power supply control
  • Battery chargers
  • Energy management
  • Active filters
  • Industrial temperature measurement

Specifications

Parameter Value Power Supply Voltage (V<sub>cc) 3V to 32V Input Offset Voltage 2 mV Operating Temperature Range -40°C to +125°C

In summary, the LM324DT is a reliable and efficient solution for designers looking for a general-purpose operational amplifier that can be used in a multitude of applications. Its robustness, combined with STMicroelectronics' commitment to quality, ensures that this component will continue to be a go-to choice for both hobbyists and professionals alike.
