Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Clock/Calendar
Features Leap Year, NVSRAM
Memory Size 56B
Date Format YY-MM-DD-dd
Supply Voltage - Operating 4.5 V to 5.5 V
Voltage - Supply, Battery 2.5 V to 3.5 V
Current - Timekeeping (Max) 100μA (Typ) @ 4.5V to 5.5V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 020926-M41T56M6F
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name M41T56
Introduction Date March 01, 1999
ECCN EAR99
Country of Origin Malaysia, Morocco, Philippines
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian M41T56M6F CAD Model

Description

The M41T56M6F is a low-power serial real-time clock (RTC) with a built-in 32.768 kHz oscillator (external crystal controlled) and an embedded crystal. Manufactured by STMicroelectronics, a leader in the semiconductor industry, this RTC is a highly integrated timekeeping solution that offers a wide range of features and benefits for a variety of applications.

Key Features

  • Timekeeping Accuracy: The device maintains accurate timekeeping with an embedded crystal that helps in reducing the external component count.
  • Low Power Consumption: Designed for battery-powered applications, the M41T56M6F consumes very low power, which helps in prolonging the battery life of the host device.
  • Serial Interface: It includes an I2C-compatible (400kHz) serial interface, which facilitates easy integration into various systems and ensures simple communication with microcontrollers.
  • Additional Features: It comes with a range of features, including a programmable alarm, a programmable square wave output, and a serial interface watchdog function, making it highly versatile for complex applications.

Applications

The M41T56M6F is suitable for a wide range of applications, such as:

  • Portable devices
  • Industrial systems
  • Medical equipment
  • Utility meters
  • Consumer electronics

Technical Specifications

Feature Specification Package SOPH-8 Operating Voltage 2.7V to 5.5V Operating Temperature -40°C to +85°C Counters Seconds, Minutes, Hours, Day, Date, Month, Year, and Century Interface I2C Serial

Conclusion

In summary, the M41T56M6F from STMicroelectronics is a feature-rich real-time clock module that offers high accuracy, low power consumption, and a host of additional features, making it an excellent choice for designers who require a reliable timekeeping component in their electronic projects.
