Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Obsolete(EOL)
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 12.5A
Voltage - Forward (Vf) (Max) @ If 140mV @ 10A
Current - Reverse Leakage @ Vr 1μA @ 30V
Mounting SMD (SMT)
Case / Package 8-PQFN (5x6)
Operating Temperature - Junction -45°C to 150°C
Win Source Part Number 1101657-SPV1001N40
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SPV1001N40
Introduction Date June 20, 2011
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian SPV1001N40 CAD Model

Description

The SPV1001N40 is a cutting-edge power bypass diode designed and manufactured by STMicroelectronics, a leader in semiconductor solutions. This component is specifically engineered for photovoltaic (PV) applications and is an integral part of solar panel setups. The SPV1001N40 ensures that the power generated by solar panels is efficiently transferred to the storage or grid, minimizing losses due to shading or panel mismatch.

Key Features

  • High Voltage Capability: With a maximum repetitive reverse voltage (VRRM) of 40V, the SPV1001N40 is suitable for high-voltage solar arrays, providing flexibility in system design.
  • Low Forward Voltage Drop: The low forward voltage drop (VF) characteristic reduces power losses during operation, which is crucial for maintaining the efficiency of the solar power system.
  • High Junction Temperature: The device can operate at a high junction temperature, allowing for continued performance even under extreme weather conditions.
  • Robust Package: Encased in a robust package, the SPV1001N40 is designed to withstand harsh environmental conditions commonly found in outdoor solar installations.

Applications

The SPV1001N40 is primarily used in photovoltaic systems to prevent reverse currents that can be caused by shaded or defective solar cells. This diode is a critical component in:

  • Solar Panel Junction Boxes
  • PV Power Stations
  • Grid-Connected Solar Applications
  • Off-Grid Solar Installations

Reliability and Safety

STMicroelectronics is committed to providing products that meet the highest standards of reliability and safety. The SPV1001N40 is no exception, as it undergoes rigorous testing to ensure it meets the stringent requirements of the photovoltaic industry. Its long-term reliability contributes to the overall durability and lifespan of solar power systems.

Environmental Impact

As a component in renewable energy systems, the SPV1001N40 plays a role in reducing the carbon footprint by enabling more efficient solar power generation. By minimizing energy losses, it supports the global shift towards sustainable energy solutions.
