Product Overview: SPV1002D40 - STMicroelectronics

The SPV1002D40 is a high-performance, advanced power bypass diode designed and manufactured by STMicroelectronics, a global semiconductor leader known for its innovative and reliable components. This product is specifically engineered to enhance the efficiency and longevity of photovoltaic (PV) systems, making it an ideal solution for solar panel installations.

Key Features

• High Voltage Rating: The SPV1002D40 is capable of handling up to 40V, which makes it suitable for high-voltage solar panels and string configurations.
• Low Forward Voltage Drop: With a low forward voltage drop, this diode ensures minimal power loss, thereby maximizing the overall efficiency of the PV system.
• Large Current Capability: It is designed to carry a substantial amount of current, which is crucial for large-scale solar installations that generate significant power outputs.
• High Junction Temperature: The device can operate at high temperatures, which is a common scenario in outdoor solar applications, without compromising its performance or reliability.
• Robust Package: Housed in a rugged package, the SPV1002D40 is built to withstand harsh environmental conditions, including high humidity and temperature variations.

Applications

The SPV1002D40 is specifically designed for solar power applications. It is typically used as a bypass diode in solar panels to prevent hot-spot heating and power loss when cells are partially shaded or damaged. Its robust design ensures that it can be deployed in various environments, from residential rooftops to commercial solar farms.

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The SPV1002D40 is no exception, as it adheres to stringent quality control standards and is built with reliability in mind. This diode is a testament to STMicroelectronics' dedication to providing components that enhance the performance and dependability of renewable energy systems.

Technical Support and Resources

Customers can access a wealth of technical resources, including datasheets, application notes, and design tools, to facilitate the integration of the SPV1002D40 into their solar solutions. STMicroelectronics also offers dedicated support from its team of experts to help with design-in processes and to address any technical queries.
