Products specifications

Category Development Boards, Kits, Programmers>Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Mfr STMicroelectronics
Package Bulk
Main Purpose DC/DC, Step Down
Outputs and Type 1, Non-Isolated
Voltage - Output 1.9V ~ 2.8V
Current - Output 400mA
Voltage - Input 1.8V ~ 5.5V
Regulator Topology Buck
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part ST1PS01
Base Product Number STEVAL
Other Names 497-19444,-1138-STEVAL-1PS01AJR
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8543.70.9860
Win Source Part Number 1284251-STEVAL-1PS01AJR
Ultra Librarian 3D Model Ultra Librarian STEVAL-1PS01AJR CAD Model

Description

The STEVAL-1PS01AJR is an advanced evaluation board from STMicroelectronics, designed to showcase the capabilities of the VIPerPlus series of high-voltage converters. This innovative product is an excellent tool for engineers and designers looking to evaluate and prototype power supply solutions for a variety of applications.

Key Features

  • High-Voltage Capabilities: The board is built to handle high voltages efficiently, making it suitable for applications requiring a robust power supply.
  • Integrated VIPerPlus Converters: Equipped with the latest VIPerPlus power converters, the STEVAL-1PS01AJR offers improved energy efficiency and reliability.
  • Flexible Power Management: It provides versatile power management options, allowing for optimization of power consumption and performance.
  • Compact Design: The compact size of the evaluation board makes it easy to integrate into various designs without taking up excessive space.
  • Comprehensive Protection Features: The board includes features such as overvoltage protection, overcurrent protection, and thermal shutdown to ensure the safety and longevity of your designs.

Applications

The STEVAL-1PS01AJR is suitable for a wide range of applications, including but not limited to:

  • Power supplies for consumer electronics
  • Industrial control systems
  • Smart home devices
  • LED lighting systems

Technical Specifications

The board supports input voltages ranging from a minimum to a maximum specified by the VIPerPlus series datasheets. It also features a variety of output voltage configurations to cater to different needs, ensuring versatility in application.

Design Resources

STMicroelectronics provides comprehensive technical documentation for the STEVAL-1PS01AJR, including schematics, user manuals, and application notes. This wealth of resources is designed to assist developers in quickly understanding and utilizing the board to its full potential.

Whether you are developing power supplies for consumer electronics, industrial applications, or innovative smart devices, the STEVAL-1PS01AJR evaluation board from STMicroelectronics offers the performance, efficiency, and reliability required to bring your projects to life.
